Cut and bevel in one pass, cold

Most plate edge preparation is a two-step operation: cut the plate to size on a shear, plasma or laser, then bevel the edge on a separate machine or by grinding. Each step moves the plate, adds handling time and introduces its own error. A rolling cutting and beveling machine such as the GD20 does both at once — the plate is sheared to width and the edge is formed to the weld preparation in a single cold pass.

Because the process is mechanical, there is no heat-affected zone, no oxide layer and no dross to grind off. That matters for two reasons: the bevel face is immediately ready for welding without the oxide removal that thermal cutting requires, and the plate metallurgy at the edge is unchanged — which is why the process is preferred for pressure vessel and tank work where a thermally cut edge would need dressing before welding.

GD20 rolling cutting and beveling machine forming a bevel on a steel plate edge

How the machine works

A powered roller pair feeds the plate through the machine at a controlled speed. Cutting rolls trim the edge to the set width, and beveling rolls then form the edge angle. Because the plate never leaves the machine between the two operations, the bevel is referenced to the cut edge — so the finished bevel position is accurate relative to the plate width, which is not true when cutting and beveling are separate operations.

Two consequences follow for the shop:

  • Plate width tolerance becomes the bevel tolerance. If the cut edge is straight, the bevel is straight. A warped plate entering the machine produces a bevel that wanders.
  • Setup is per thickness and per bevel angle. Changing the plate thickness or the bevel angle requires re-setting the rolls, so the machine is most efficient when parts are batched by thickness rather than run in mixed order.

Comparison with other edge preparation methods

MethodEdge qualityHeat effectSpeedBest for
Rolling cutting + bevelingClean, cold-worked, ready to weldNoneHigh for straight edgesCarbon steel plate in tanks, vessels, general fabrication
Flame cuttingRequires grinding; oxide layerHAZ, needs dressing for some codesModerateThick carbon plate, complex profiles
Plasma cuttingGood top edge, dross on bottomNarrow HAZHighStainless and aluminium, profiles
Edge milling (XBJ class)Machined, best finish and toleranceNoneSlowerStainless, clad, thick plate, code-critical bevels
Hand grindingOperator-dependentLocal heatingSlowRepair and touch-up only

The practical decision is usually between rolling beveling and milling. Rolling is faster and cheaper for carbon steel plate in production quantities; milling gives a machined finish and holds tighter angular tolerance, which is what stainless, clad and thick-section code work needs.

Bevel geometry and what the welding procedure wants

Edge preparation is not just an angle. The welding procedure specification defines the bevel angle, the root face and the root gap, and a bevel cut to the wrong root face has the same effect as an undersized weld: incomplete penetration at the root. On a rolling beveling machine the root face is set by the roll arrangement, so it has to be checked on the first part of each batch, not assumed from the setting used for the previous thickness.

Beveled plate edges produced by a rolling cutting and beveling machine

Applications

  • Tank and vessel shells — longitudinal seam edges, where a clean cold bevel removes the need for pre-weld dressing.
  • Pipe and penstock fabrication — plate edges before rolling into cans.
  • Structural and general fabrication — plate preparation ahead of welding.
  • Workshops without a plate milling machine — a rolling beveler covers most carbon steel preparation at a lower capital cost.

Specifying a GD20

To quote one we need: plate thickness range, plate length and weight to be handled, bevel angle range and whether a specific root face is required, plate material (carbon steel for rolling; stainless and aluminium normally need a milling solution), throughput required in plates per shift, and the shop layout including how plate is fed to and taken from the machine. Mechanical edge preparation covers plate thickness ranges up to roughly 80 mm across the DESAN edge preparation range, with the specific GD20 configuration confirmed against the thickness list.

Minimum order quantity is 1 set. Standard machines ship in 30–50 days after deposit; customised infeed and outfeed arrangements are scheduled in the technical proposal. Payment terms are T/T; trade terms are FOB, FCA or CIF. Core ranges are CE compliant and supplied against a certificate of compliance.

Plate processing equipment is supplied under the DESAN brand by DESAN ELECTRIC LTD, which has served 1,000+ customers in 20+ countries over 20+ years with engineering experience since 1997. For machined bevels on stainless, clad or heavy plate, see the plate edge milling machine.
